PRODUCTION
1080i/720p switchable Ross Carbonite HD production switcher
2 ME 18 input/10 outputs
Internal Animation & Still-Store w/1 inputs & 4 outputs
CAMERAS
2 Sony PMW320 HD Cameras with CCU and RCP – Wired for SingleMode
3 Sony FB75 HD Cameras with CCU – Wired for SingleMode
4 Sony RCP920 Control Panels
4 Sony HXCEFB70 Power Supply Extension Units
2 Marshall HD POV/ENG cams
LENSES
1 Canon 55×8.8 Sports Box Lens (semi-servo)
1 Fujinon 12×4.5 Lenses
2 Fujinon 22X Lenses
1 Fujinon 18×5.5 Lenses
REPLAY/RECORDING
1 NEWTEK 3-Play 425 HD 6 channel broadcast server. 4 In/2 Out
1 Grass Valley Turbo iDDR 2Ch in/1 CH out
1 Black Magic Hyperdeck Studio
1 Black Magic Hyperdeck Mini
GRAPHICS
Ross Xpression Studio
Chyron DUET (upon Request)
CAMERA SUPPORT
1 Vinten Vector 50 head
3 Vinten 10 heads
1 Quickset Heavy Duty Sticks
4 Vinten heads/sticks
MONITORING
2 50” LCD Multiview
5 23″ LCDs
COMMUNICATIONS
JK Audio IP/Phone Hybrid Phone system
Clear Com 4 ch. IFB system
Clear Com PL System - 2 Channel
10 Walkie Talkie Style Radios
TERMINAL
HD492 iCap Digital Closed Captioning Encoder (upon request)
Ensemble Designs Bright Eye 90 UDC
4 BlackMagic UDC
1000′ TAC-4 Fiber (SM LC Termination)
1000′ TAC-4 Fiber (MM LC Termination)
2 250′ TAC-12 Fiber (SM LC Termination)
4 - 1000’ OpticalCon DUO Fiber Reels for Cams
4 – 25’ OpticalCon DUO Fiber for Cams
2 AJA Fido Kits
Handful of SDI to HDMI convertors
Black Magic, 40x40 HD SDI router
2 Black Magic Smart Control Hub Panels
Evertz GPS 5601 Master Clock
Fujitsu IP-920 Streaming Device
T21 Streaming Device
Teradek SLICE Streaming Device
AUDIO (INTERNAL)
Behringer 32Ch MIxer
2 Behinger Remote S16 Remote I/O Rack
Denon SD Audio PLayer
Genelec Monitoring
Dolby Loudness LM10 Loudness Monitoring
Wohler Monitoring
AUDIO (EXTERNAL)
1 250’ 8 Channel Snake
1 250’ 12 Channel Snake
2 500’ DT12
2 Sennheiser HMD27 Broadcast Headsets
3 Audio Technica BPHS1 Sportscaster Headsets
2 Shure SM58 Hand Mics
2 Sony ECM77B Lavs
2 Sennheiser ME66 Shotgun Mics
6 ClearCom 1Ch Beltpacks
6 ClearCom Dual/Single Muff Headsets
2 ClearCom 2 Ch. Biscuit Boxes
3 Studio Technologies announce consoles
DIMENSIONS
Trailer Only 8.5′ x 24′ x 13’6″
5000lbs
POWER REQUIREMENTS
208-240 VAC Three Phase 100 A
